CSG SPL, KSB-9, BDY, 11-5M FLG TOP X 13 5/8 5M FLG BTTM , W/ (2) 2 1/16-5M STDD OUTLETS, 1 1/2 VRP AND DOUBLE "FS" SEAL

China CSG SPL, KSB-9, BDY, 11-5M FLG TOP X 13 5/8 5M FLG BTTM , W/ (2) 2 1/16-5M STDD OUTLETS, 1 1/2 VRP AND DOUBLE "FS" SEAL supplier
CSG SPL, KSB-9, BDY, 11-5M FLG TOP X 13 5/8 5M FLG BTTM , W/ (2) 2 1/16-5M STDD OUTLETS, 1 1/2 VRP AND DOUBLE "FS" SEAL supplier

Large Image :  CSG SPL, KSB-9, BDY, 11-5M FLG TOP X 13 5/8 5M FLG BTTM , W/ (2) 2 1/16-5M STDD OUTLETS, 1 1/2 VRP AND DOUBLE "FS" SEAL

Product Details:

Place of Origin: P.R.CHINA
Brand Name: VigorPetro
Certification: API 6A, ISO 9001
Model Number: C22

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Box
Delivery Time: 20-30 Days
Payment Terms: T/T, Western Union
Supply Ability: 100 Sets/50 Days
Contact Now
Detailed Product Description
Bottom Size: 13 5/8" 5M Top Size: 11" 5m
Side Outlet: 2-1/16" 5M Studded PSL: PSL1-PSL3
PR: PR1-PR2 Temp.: SU
Metrial Class: EE STD: API 6A

CSG SPL, KSB-9, BDY, 11-5M FLG TOP X 13 5/8 5M FLG BTTM , W/ (2) 2 1/16-5M STDD OUTLETS, 1 1/2 VRP AND DOUBLE "FS" SEAL PREP. F/ 9 5/8 CSG PSL: 2 Temp: P-U Matl. Class: FF-NL 410SS/75K





CSG SPL, KSB-9, BDY, 11-5M FLG TOP X 13 5/8 5M FLG BTTM , W/ (2) 2 1/16-5M STDD OUTLETS, 1 1/2 VRP AND DOUBLE "FS" SEAL

Description: FORGING,CASING SPOOL, KSBT-0/KSB-9, 11" API 10M FLANGE TOP X 13-5/8" API 5M FLANGE BOTTOM,W/ (2) 2" API LP OR 2-1/16" API 5M STUDDED OUTLETS, 8.43 THRU BORE ID, 26.77 OAL. PSL: 3 Temp: P-U Matl. Class: FF-NL 410SS/75K. THEFOLLOWING:
- 2-1/16'' GATE VALVE 5M WP FLANGED END INCLUDING HANDWHEEL
- 2-1/16'' COMPANION FLANGE X 2'' LP FEMALE THREAD
- 2-1/16'' BLIND FLANGE 5000PSI
- BULL PLUG 2'' LP X 1/2'' LP
- NEEDLE VALVE 1/2'' NPT 10000 PSI
- PRESSURE GAUGE 0-2000 PSI RANGE STAINLESS STEEL CASE FILLED WITHGLYCERIN
- API RING GASKET RX-54 AND RX-24
