Product Details:
Payment & Shipping Terms:
|
| Product: | Sand Filter Vessel (Pot) | Flow Line Connection: | 3-1/16” X 10K Flanged |
|---|---|---|---|
| Liquid Flow Capacity: | 5,000 Bpd | Holding Capacity Of Vessel: | 180 Liters |
| Vessel (Pot)OD: | 356 Mm / 14” | Vessel (Pot)Length: | 3054 Mm / 120-1/4” Approx |
| Filter Element OD: | 114 Mm / 4-1/2” | Filter Mesh Sizes (Wire Screen): | 100 And 200 Microns |
| Filter Collapse Pressure: | 1500 PSI | Inlet Port CD From Top: | 406 Mm / 16” |
| Inlet Port Size: | 3-1/16” Flanged | Outlet Port At Bottom Studded Connection: | 3-1/16” X 10K Studded |
| Flush Line Outlet CD From Bottom: | 419 Mm / 16.5” | Flush Line Outlet Size: | 2” 1502 Weco Union |
| Vessel End Cap: | Threaded(Acme) With Plug | Flow Direction: | Outside → Inside |
Data Sheet: Sand Filter Vessel (Pot) Assembly, 3-1/16" 10000PSI Inlet & Outlet X 2" 1502 Flush Line Outlet
| Sand Filter Vessel (pot) Assembly as per attached drawing, | ||||
| Service | H2S | |||
| Material Class | DD | |||
| Working Pressure | 10,000 PSI | |||
| Working Temperature Range | -29˚ C to 121˚ C | |||
| Flow Line Connection | 3-1/16” x 10K Flanged | |||
| Liquid Flow Capacity | 5,000 Bpd | |||
| Holding Capacity of Vessel | 180 Liters | |||
| Vessel (Pot)OD | 356 mm / 14” | |||
| Vessel (Pot)Length | 3054 mm / 120-1/4” Approx | |||
| Filter Element OD | 114 mm / 4-1/2” | |||
| Filter Mesh Sizes (Wire screen) | 100 and 200 Microns | |||
| Filter Collapse Pressure | 1500 PSI | |||
| Inlet Port CD from Top | 406 mm / 16” | |||
| Inlet Port Size | 3-1/16” Flanged | |||
| Outlet Port at Bottom Studded Connection | 3-1/16” x 10K Studded | |||
| Flush Line Outlet CD from Bottom | 419 mm / 16.5” | |||
| Flush Line Outlet Size | 2” 1502 Weco Union | |||
| Vessel End Cap | Threaded(Acme) with plug | |||
| Flow Direction | Outside → Inside | |||
